Ground Speed - Forward
Up To 17.7 km/h
Seat
High back comfort with suspension and padded armrests
Construction
STEEL Tubular frame welded
ROPS
Foldable ROPS Standard
Controls
Hand-operated choke, throttle, ignition switch, electric mower clutch, Hand Park brakes
Deck System
X-Factor® 3 Fabricated
Deck Construction
Fabricated 7 Gauge w' 1/4" Spindle Reinforcement
Blade Drive
V-belt drive to spindles with electric clutch. Spring tension idler pulleys for extended belt life
Spindles
Forged Aluminium with sealed ball bearings
Drive System
Parker HTJ 12cc Dual Hydrostatic Transmission
Discharge Chute
High density, rubberised
Steering
Twin-lever steering provides independent control of each drive wheel. Speed, forward, reverse, and turns are all controlled with hand-operated controls.
Type
Air cooled, 90-degree V-twin, normally aspirated petrol engine
Cooling
Air cooled flywheel fan
Fuel
Unleaded fuel - maximum of 10% ethanol in fuel (see engine manufacturers specifications)
Fuel Filter
Replaceable, automotive-type
Oil Filter
Spin-on engine oil filter / Total oil capacity 2.1 litres with filter
Air Filter
Multi-Stage remote canister heavy duty air filter system
